Product Name: Outdoor 8 pin ip68 waterproof circular connector DC-008
Part Number: HTP-DC-008
- Type：M round waterproof connector;
- Assembly way: Welding/Soldering, Injection Molding;
- Application: Vehicle，Electric car，Medical equipment, etc.
Outdoor 8 pin ip68 waterproof circular connector DC-008
2020-04-06 04:58:09 1827Product Name：Outdoor 8 pin ip68 waterproof circular connector DC-008Product ID：HTP-DC-008- Type：M round waterproof connector;- Assembly way: Welding/Soldering, Injection Molding;- Application: Ve
- Trademark : HYTEPRO®
- Part Number : HTP-DC-008
- Number of Pins : 8
- Waterproof Rate : IP67~IP68(IEC-60529)
- Operating temperature : -40~+105℃
- Contactor : Copper with Gold plated
- Contact Impedance : 30MΩ max.
- Housing : Nylon
- Insulation Resistance : 2000MΩ/Min
- Assembly Method : Screwfix,Welding,Overmolding
- Rated Current : Small pin 2A, large pin 40A
- Type : Male for Board,Feamle for Wire
- RoHS : Compliant
- Customizable : Yes
