Feature and function:- Custom USB adapter PCB board module for power charging.- Internal integrated multi USB hub pcb with XH2.54 VH3.96 connector.- 24V power input, with 2ports of 5V output and 12V m

  • Trademark : HYTEPRO®
  • Part Number : HTP-PCBA-H68
  • Substrate material : FR-4
  • Mode : PCB-Assembly
  • Layer : 2
  • Application : USB Multi-port (Only Charge)
  • Ports : 2
  • Transmission Rate : 5Gbps
  • Input : Micro USB Female
  • Output : Terminal connector
  • Power Output : 5V 0.5A [USB2.0 regular charging]
  • Logo Printed : Support
  • Packing : Vacuum bag / bubble bag / pearl cotton / anti-static bag
  • RoHS : Compliant
  • Customizable : Yes
X
Samples Request? Get quotation list?
We will reply to you within 30 minutes
Product Name:5V power charging usb hub pcb design with LED and switch H68

Product Name: 5V power charging usb hub pcb design with LED and switch H68

Part Number: HTP-PCBA-H68

Feature and function:

- Custom USB adapter PCB board module for power charging.

- Internal integrated multi USB hub pcb with XH2.54 VH3.96 connector.

- 24V power input, with 2ports of 5V output and 12V motherboard power supply ports.

- WIth LED indicator to show the board working status,with power switch to control off/on.

- Support several device charging at the same time.

- With overcharge, overvoltage and short circuit production for this board design.

- HytePro provide PCB board developing and manufacturing solution over 11 years for various usb hub types.
